Screw size Ball DIA.

Effective
turns
circuitxrow

 BASIC RATE LOAD(kgf) Nut Flange Fit Bolt Oil hole Stiffness
O.D. Lead Dynamic
(1×106 REV.)
Ca

Static

Co

 Dg6

L

 A T W G H S X Y Z Q kgf/μm
20 4 2.381 2.5x1x(2) 450 1060 40 50 63.5 11 51 21 42 10 5.5 9.5 5.5 M6x1P 32
3.5x1x(2) 600 1480 60 49
5 3.175 2.5x1x(2) 830 1730 44 56 67 11 55 26 52 15 5.5 9.5 5.5 M6x1P 40
3.5x1x(2) 1110 2420 65 55
6
 3.969 2.5x1x(2) 1100 2120 48 67 71 11 59 27 54 15 5.5 9.5 5.5 M6x1P 41
8 3.969 2.5x1x(2) 1100 2120 48 78 75 13 61 27 54 15 6.6 11 6.5 M6x1P 41
25 4 2.381 2.5x1x(2) 510 1355 46 50 69 11 57 26 52 15 5.5 9.5 5.5 M6x1P 43
2.5x2x(2) 930 2710 74 84
5 3.175 2.5x1x(2) 910 2150 50 55 73 11 61 28 56 15 5.5 9.5 5.5 M6x1P 48
2.5x2x(2) 1650 4300 85 92
6 3.969 2.5x1x(2) 1210 2680 53 62 76 11 64 29 58 15 5.5 9.5 5.5 M6x1P 49
2.5x2x(2) 2190 5360 98 94
8 4.762 2.5x1x(2) 1560
 3200 58 77 85 13 71 32 64 15 6.6 11 6.5 M6x1P 50
10 4.762 2.5x1x(2) 1560 3200 58 100 85 15 71 32 64 15 6.6 11 6.5 M6x1P 50
28 5 3.175 2.5x1x(2) 950 2470 55 56 83 12 69 31 62 15 6.6 11 6.5 M8x1P 52
2.5x2x(2) 1720 4940 86 101
6 3.969 2.5x1x(2) 1270 3000 55 63 83 12 69 31 62 15 6.6 11 6.5 M8x1P 53
2.5x2x(2) 2300 6000 100 103
10 4.762 1.5x1x(2) 1045 2120 60 74 93 15 76 36 72 15 9 14 8.5 M8x1P 34
32 4 2.381 2.5x1x(2) 565 1750 54 50 81 12 67 32 64 15 6.6 11 6.5 M6x1P 52
2.5x2x(2) 1020 3500 76 101
5 3.175 2.5x1x(2) 1010 2840 58 57 85 12 71 32 64 15 6.6 11 6.5 M8x1P 58
2.5x2x(2) 1830 5680 87 112
6 3.969 2.5x1x(2) 1330 3450 62 63 88 12 75 34 68 15 6.6 11 6.5 M8x1P 59
2.5x2x(2) 2410 6900 99 114
8 4.762 1.5x1x(2) 1110 2510 66 64 100 15 82 38 76 15 9 14 8.5 M8x1P 37
2.5x2x(2) 1720 4180 80 61
10 6.35 1.5x1x(2) 1660 3260 74 78 108 15 90 41 82 15 9 14 8.5 M6x1P 39
2.5x1x(2) 2570 5440 97 64
12 6.35 1.5x1x(2) 1660 3260 74 88 108 18 90 41 82 15 9 14 8.5 M8x1P 39
2.5x1x(2) 2570 5440 110 64
36 5 3.175 2.5x1x(2) 1060 3210 65 60 98 15 82 38 76 15 9 14 8.5 M8x1P 64
2.5x2x(2) 1920 6420 90 123
6 3.969 2.5x1x(2) 1430 3950 65 66 98 15 82 38 76 15 9 14 8.5 M8x1P 65
2.5x2x(2) 2600 7900 102 126
10 6.35 1.5x1x(2) 1750 3710 75 81 118 18 98 45 90 15 11 17.5 11 M8x1P 43
2.5x1x(2) 2720 6180 103 70
40 5 3.175 2.5x1x(2) 1090 3560 67 60 101 15 83 39 78 15 9 14 8.5 M8x1P 69
2.5x2x(2) 1980 7120 90 133
6 3.969 2.5x1x(2) 1500 4420 70 66 104 15 86 40 80 15 9 14 8.5 PT1/8" 71
2.5x2x(2) 2720 8840 102 138
8 4.762 2.5x1x(2) 1900 5270 74 83 108 15 90 41 82 15 9 14 8.5 PT1/8" 73
2.5x2x(2) 3450 10540 131 141
10 6.35 1.5x1x(2) 1860 4710 82 81 124 18 102 47 94 20 11 17.5 11 PT1/8" 47
2.5x2x(2) 2880 6950 103 76
3.5x1x(2) 3850 9730 121 105
12 6.35 2.5x1x(2) 2880 6950 86 112 128 18 106 48 96 20 11 17.5 11 PT1/8" 76
45 10 6.35 2.5x1x(2) 3020 7850 88 101 132 18 110 50 100 20 11 17.5 11 PT1/8" 84
12 7.144 2.5x1x(2) 3550 8950 90 112 132 18 110 50 100 20 11 17.5 11 PT1/8" 85
50 5 3.175 2.5x1x(2) 1210 4420 80 60 114 15 96 43 86 15 9 14 8.5 PT1/8" 83
6 3.969 2.5x2x(2) 2980 11000 84 103 118 15 100 45 90 15 9 14 8.5 PT1/8" 164
8 4.762 2.5x2x(2) 3900 13020 87 134 129 18 107 49 98 20 11 17.5 11 PT1/8" 170
10 6.35 2.5x1x(2) 3190 8710 93 101 135 18 113 51 102 20 11 17.5 11 PT1/8" 91
2.5x2x(2) 5790 17420 161 177
3.5x1x(2) 4260 12190 121 126
12 7.144 2.5x1x(2) 3700 10050 100 116 146 22 122 55 110 20 14 20 13 PT1/8" 92
55 10 6.35 2.5x1x(2) 3310 9770 102 101 144 18 122 54 108 20 11 17.5 11 PT1/8" 98
2.5x2x(2) 6005 19540 161 191
63 10 6.35 2.5x1x(2) 3510 11200 108 105 154 22 130 58 116 20 14 20 13 PT1/8" 110
2.5x2x(2) 6370 22400 165 213
12 7.938 2.5x1x(2) 4770 13780 115 124 161 22 137 61 122 20 14 20 13 PT1/8" 113
